SPRINTER 4000 START

SPRINTER 4000 START

Download PDF Request Info

Battery charger and starter: WET, EFB 12/24V battery charger and rapid ignition of all types of vehicles, vans, etc. (400A max).
Normal charge, boost, rapid ignition selection.
Display of charging and ignition current.
Protection against overcharging and pole inversion.

Battery charger and starter: WET, EFB 12/24V battery charger and rapid ignition of all types of vehicles, vans, etc. (400A max).
Normal charge, boost, rapid ignition selection.
Display of charging and ignition current.
Protection against overcharging and pole inversion.

Battery charger and starter for charging WET/EFB batteries with 12V/24V voltage and starting all kinds of cars, vans and light trucks.
Features:

Choice of normal charge, quick charge (BOOST), quick start;
Display of charging and starting current;
Protection against overloads and polarity reversal.

Equipped with cables with clamps.

CODE

829491

SINGLE PHASE MAINS VOLTAGE

230 V

MAINS FREQUENCY

50 / 60 Hz

CHARGE POWER

2 kW

START POWER

12 kW

CHARGING VOLTAGE

12 / 24 V

EFFECTIVE CHARGING CURRENT

90 A

RATED CHARGE CURR. EN60335-2-29

60 A

START CURRENT 1V/C EN60335-2-29

300 A

MAX STARTING CURRENT

400 A

MIN. RATED REFERENCE CAPACITY

20 Ah

MAX RATED REFERENCE CAPACITY

1000 Ah

ADJUSTMENT POSITIONS

4

DIMENSIONS

26,1 x 39,5 x 80,8 cm

WEIGHT

18,4 kg

Catalog Image

Instruction Manual

Spare Parts List

Certificate

BATTERY CHARGERS FUSES

FUSES 80A 20 PCS

Battery charger and starter for charging WET/EFB batteries with 12V/24V voltage and starting all kinds of cars, vans and light trucks.
Features:

Choice of normal charge, quick charge (BOOST), quick start;
Display of charging and starting current;
Protection against overloads and polarity reversal.

Equipped with cables with clamps.

CODE

829491

SINGLEPHASE MAINS VOLTAGE

230 V

MAINS FREQUENCY

50 / 60 Hz

CHARGING ABSORBED POWER

2 kW

STARTING ABSORBED POWER

12 kW

CHARGE AND STARTING VOLTAG.

12 / 24 V

EFFECTIVE CHARGING CURRENT

90 A

RATED CHAR.CUR.EN60335-2-29

60 A

START CUR.1V/C EN60335-2-29

300 A

MAX STARTING CURRENT

400 A

MIN.RATED REFERENCE CAPAC.

20 Ah

MAX.RATED REFERENCE CAPAC.

1000 Ah

ADJUSTMENT POSITIONS

4

DIMENSIONS (LxWxH)

26,1 x 39,5 x 80,8 cm

WEIGHT

18,4 kg

Catalog Image

Instruction Manual

Spare Parts List

Certificate

BATTERY CHARGERS FUSES

FUSES 80A 20 PCS
