TECHNOLOGY PLASMA 41 XT

TECHNOLOGY PLASMA 41 XT

Download PDF Request Info

40A plasma cutting inverter system with compressed air and strike on contact of the pilot arc. With PH torch.
Max. cut 15 mm. Fast cutting without deformation of all the conductor materials.
Live voltage signal in torch, protection; change consumables signal, air pressure display.
Automatic torch cooling: gauge metal protection cage.
Thermostatic, overvoltage, undervoltage, overcurrent protection, no air protection.
Strong and resistant to impact; reduced weight and dimensions.

40A plasma cutting inverter system with compressed air and strike on contact of the pilot arc. With PH torch.
Max. cut 15 mm. Fast cutting without deformation of all the conductor materials.
Live voltage signal in torch, protection; change consumables signal, air pressure display.
Automatic torch cooling: gauge metal protection cage.
Thermostatic, overvoltage, undervoltage, overcurrent protection, no air protection.
Strong and resistant to impact; reduced weight and dimensions.

Inverter, compressed air plasma cutting system, with contact striking of pilot arc. Allows a rapid, distortion-proof cutting of all conductive materials such as steel, stainless steel, galvanised steel, aluminium, copper, brass, etc.
Ideal for numerous applications and environments, from maintenance to bodyshops.
Features:

robust and impact resistant;
reduced weight and dimensions;
ideal for cutting hollow square pipes;
warning led for torch under voltage, protections;
torch automatic cooling;
warning led for consumables change;
visualization of air pressure;
max. cutting thickness 15mm;
manometer metallic protection;
thermostatic, overvoltage, undervoltage, overcurrent, air failure protections.

Complete with PH torch.

CODE

816146

SINGLE PHASE MAINS VOLTAGE

230 V

MAINS FREQUENCY

50 / 60 Hz

CURRENT RANGE

10 - 40 A

MAX CURRENT

35 @ 30 % A

MAX NO LOAD VOLTAGE

313 V

MAX ABSORBED CURRENT

25 A

MAX ABSORBED POWER

4 kW

EFFICIENCY

85 %

POWER FACTOR

0,7

MAX CUTTING THICKNESS

15 mm

COMPRESSED AIR CAPACITY

100 l/min

COMPRESSED AIR PRESSURE

4 - 5 bar

PROTECTION DEGREE

IP23

DIMENSIONS

47,5 x 18,2 x 29,2 cm

WEIGHT

9 kg

Catalog Image

Download IMG

Instruction Manual

Download PDF

Spare Parts List

Download PDF

brochure

Download PDF

PH PLASMA TORCH 4 M

804155

AIR PRESSURE REGULATOR

125237

CABLE TW05V-A 1X016 L=03,00M ATLAS 25MMQ

TOLEDO 300 WORK CLAMP

OTHER PLASMA ACCESSORIES

MMS-10 MOISTURE & MIXTURE STOP FILTER

804340

MMS-10 AIR FILTER CARTRIDGES 4 PCS

804343

robust and impact resistant;
reduced weight and dimensions;
ideal for cutting hollow square pipes;
warning led for torch under voltage, protections;
torch automatic cooling;
warning led for consumables change;
visualization of air pressure;
max. cutting thickness 15mm;
manometer metallic protection;
thermostatic, overvoltage, undervoltage, overcurrent, air failure protections.

Complete with PH torch.

CODE

816146

SINGLEPHASE MAINS VOLTAGE

230 V

MAINS FREQUENCY

50 / 60 Hz

CURRENT RANGE

10 - 40 A

MAX CURRENT EN60974-1

35 @ 30 % A

MAX NO LOAD VOLTAGE

313 V

MAX ABSORBED CURRENT

25 A

MAX ABSORBED POWER

4 kW

EFFICIENCY

85 %

POWER FACTOR(cosphi) (cosphi)

0,7

MAX CUTTING THICKNESS

15 mm

COMPRESSED AIR CAPAC.

100 l/min

COMPRESSED AIR PRESSURE

4 - 5 bar

PROTECTION DEGREE

IP23

DIMENSIONS (LxWxH)

47,5 x 18,2 x 29,2 cm

WEIGHT

9 kg

Catalog Image

Download IMG

Instruction Manual

Download PDF

Spare Parts List

Download PDF

brochure

Download PDF

PH PLASMA TORCH 4 M

804155

AIR PRESSURE REGULATOR

125237

CABLE TW05V-A 1X016 L=03,00M ATLAS 25MMQ

TOLEDO 300 WORK CLAMP

OTHER PLASMA ACCESSORIES

MMS-10 MOISTURE & MIXTURE STOP FILTER

804340

MMS-10 AIR FILTER CARTRIDGES 4 PCS

804343

TECHNOLOGY PLASMA XT

THE EXTREME SIDE OF CUTTING

A WORLD OF POWER

Two letters, a whole world.

XT is the line designed for those demanding maximum strength in the most extreme uses, for those seeking exceptional performance, for those wishing to push beyond the usual results. Products where efficiency, comfortable handling and easy use become daily and irreplaceable allies.

POWER / HEAVY DUTY:powerful and performing, even on the most demanding thicknesses. To deal with every job with the certainty of the best result.

PERFORMANCE:
they are the ideal tool for a fast and deformation-free cutting of all conductive materials and ensure the best performance over time thanks to the duty cycle designed for professional use.

BEYOND THE USUAL RESULTS

STRENGTH:
designed to resist impact during the most challenging works or the hardest transport.

VERSATILITY:
they ensure an eXTreme cut on all conductive materials, allow you to work even without a compressor (mod. 54 XT kompressor) and are equipped with numerous advanced functions (mod. 60 XT).

TRANSPORTABILITY:
thanks to the metal handle, the reduced weight and the robust structure, they can be transported anywhere.

QUALITY:
designed thanks to the know-how of those who have been creating products for professionals for over 55 years, with the certainty of the “Made in Italy, Made in Telwin”.

THE EFFICIENCY DETAILS

XT was designed to deal with any type of work to make everyday operations easier.

The metal handle allows a firm, safe grip, for professional use. The anti-shock bumpers make the structure impact-proof, ensuring resistance and duration over time, even in heavy use.
The centralized torch connection (DINSE socket Ø 25 mm) facilitates operation. The consumables change signaling guarantees the best performance of the product over time.
